File:Tesla Model S Rear HVJB 20b.jpg
Size of this preview: 800 × 600 pixels. Other resolutions: 2,560 × 1,920 pixels | 4,032 × 3,024 pixels.
Original file (4,032 × 3,024 pixels, file size: 1.39 MB, MIME type: image/jpeg)
Tesla Model S GEN1 Rear HVJB "parking" connector for harness WWMA2, used in Single OBC installations only. Note (3) 180 ohm resistors, connected in parallel, to obtain net 60 ohms for HVIL loop.
