Re: BMW i3 CCS/charge port controller

muehlpower wrote: Fri Jun 23, 2023 4:28 pm Have you or anyone tried charging more than 125A? In my estimation, there are two parameters to consider. 2F1h 16/8 and 3E9h 40/8
I tried and had no success to go above 125A but maybe I'm still missing a limit.
by bitterandreal
Thu Jun 15, 2023 8:55 pm
Forum: Charging
Topic: BMW i3 CCS/charge port controller
Replies: 1187
Views: 3054570

Re: BMW i3 CCS/charge port controller

Hello, I'm a bit overwhelmed with your questions. I clicked on CAFD, Edit NCD and then the "Functions" page came up. There I found settings for US or EU, LEDs, PWM for the DC contactor etc. but nothing about a 125A limit. Thanks for your reply. Too bad there is no current limit parameter....
by bitterandreal
Thu Jun 15, 2023 8:02 am
Forum: Charging
Topic: BMW i3 CCS/charge port controller
Replies: 1187
Views: 3054570

Re: BMW i3 CCS/charge port controller

@muehlpower How dit you decode the programmed LIM parameters in E-Sys?
If I try to edit them in the FDL-Editor I don't see parameter names.
Have you been using the BimmerUtility to map the CAFD?
by bitterandreal
Sun Jun 11, 2023 11:36 am
Forum: Charging
Topic: BMW i3 CCS/charge port controller
Replies: 1187
Views: 3054570

Re: BMW i3 CCS/charge port controller

What small relays did you use? And do you know if there're special requirements for the small relays? It looks like the idea is to put 15ohm resistors (in your case 30ohm), in parallel with the coil of the small ones to simulate the bmw original contactors. But if I remember correctly resistance in...
by bitterandreal
Fri Jun 09, 2023 12:37 pm
Forum: Charging
Topic: BMW i3 CCS/charge port controller
Replies: 1187
Views: 3054570

Re: BMW i3 CCS/charge port controller

How much does your voltage sense board draw? I measured a BMW I3 LIM current draw once it cycles down, it is very low. At this moment however we do not wake and shut it down properly over canbus using the Power Management CAN bus message, 0x12f. It might be possible to shutdown the BMW I3 CCS Contr...
by bitterandreal
Thu Jun 08, 2023 12:31 pm
Forum: Charging
Topic: BMW i3 CCS/charge port controller
Replies: 1187
Views: 3054570

Re: BMW i3 CCS/charge port controller

As already written, I use nothing but a Vector CAN card, 12V supply and E-Sys. I have the Fahrzeugauftrag (FA) as a file and do not need to read it from the key. Due to the direct connection with the Vector Card, I don't need a BCD as a gateway either. I don't know how to sort the pictures, so I nu...
by bitterandreal
Thu Jun 08, 2023 9:58 am
Forum: Charging
Topic: BMW i3 CCS/charge port controller
Replies: 1187
Views: 3054570

Re: BMW i3 CCS/charge port controller

Now on vcu 2.0 firmware and working. But the thing why the welding test is not performing is that the CP_DOOR always starts in error state. I have a switch on the charge cap and I need to open the cap for a couple of seconds, then de CP_DOOR goes to open sand then I can close it again and it report...
by bitterandreal
Sat May 06, 2023 10:49 am
Forum: Charging
Topic: BMW i3 CCS/charge port controller
Replies: 1187
Views: 3054570

Re: BMW i3 CCS/charge port controller

nathaniel wrote: Wed May 03, 2023 8:40 pm i have made a self build isa shunt based on a ESP32 because i find them to expensive, and on there a also put a DAC for this purpose...
A custom high voltage and current sensor board sounds very interesting.
by bitterandreal
Sun Mar 05, 2023 8:59 pm
Forum: Charging
Topic: BMW i3 CCS/charge port controller
Replies: 1187
Views: 3054570

Re: BMW i3 CCS/charge port controller

I played around with coding the LIM today. I use a Vector CANoe card and E-Sys, with which I can establish a direct connection to the LIM. I also have an FA (Fahrzeugauftrag) as a file, so I don't need another BMW device. After reading out the coding, there are many setting options, such as AC conn...
by bitterandreal
Wed Mar 01, 2023 10:02 am
Forum: Charging
Topic: BMW i3 CCS/charge port controller
Replies: 1187
Views: 3054570

Re: BMW i3 CCS/charge port controller

muehlpower wrote: Wed Mar 01, 2023 9:47 am I don't know how Damien does it, but I can choose which country and standard. I can also edit the VIN.
How are you doing that?
by bitterandreal
Sat Feb 25, 2023 1:24 am
Forum: Charging
Topic: BMW i3 CCS/charge port controller
Replies: 1187
Views: 3054570

Re: BMW i3 CCS/charge port controller

The wiki states some states which are not implemented in the code. Can anyone confirm that these steps are required to get past the Pre-charge state with a new LIM? The CAN log's shows 0x88 in byte 2 of message 0x12F and the DBC decodes it as "KLR_ON" In https://github.com/damienmaguire/St...
by bitterandreal
Sat Dec 03, 2022 9:21 am
Forum: Charging
Topic: BMW i3 CCS/charge port controller
Replies: 1187
Views: 3054570

Re: BMW i3 CCS/charge port controller

I would not expect the LIM to actually support charging up to 1000V.
DIN 70121 was limited to 500V and at some point they moved to ISO 15118 which supports 1000V.
But only because the protocol supports it the LIM does not have to...
by bitterandreal
Mon Aug 15, 2022 3:18 pm
Forum: Charging
Topic: BMW i3 CCS/charge port controller
Replies: 1187
Views: 3054570

Re: BMW i3 CCS/charge port controller

While trying to understand what the screenshot of the programming log tells I found this post which is not really related but still explains a bit... E-sys installation instructions suggest to un-check "Update VCM" & "MSM." These stand for Vehicle Configuration Management &am...
by bitterandreal
Sun Aug 14, 2022 7:40 pm
Forum: Charging
Topic: BMW i3 CCS/charge port controller
Replies: 1187
Views: 3054570

Re: BMW i3 CCS/charge port controller

A UDS bootloader would be a very nice feature for the open inverter devices. 😀
by bitterandreal
Wed Nov 10, 2021 10:07 pm
Forum: Charging
Topic: BMW i3 CCS/charge port controller
Replies: 1187
Views: 3054570

Re: BMW i3 CCS/charge port controller

brianbri6 wrote: Wed Nov 10, 2021 10:03 pm Yes I've seen the wiki before but I'm wondering because it has AC_DCC instead of AC_DCO is that for chademo?
The wiki says:
Only AC_DCO versions work for CCS. (Check if you have a MAC address on the label!)
by bitterandreal
Wed Nov 10, 2021 9:57 pm
Forum: Charging
Topic: BMW i3 CCS/charge port controller
Replies: 1187
Views: 3054570

Re: BMW i3 CCS/charge port controller

brianbri6 wrote: Wed Nov 10, 2021 8:48 pm Hi everyone I've been watching development for a bit. I would like to know if this module is DC fast charging capable.
Read the wiki first…
https://openinverter.org/wiki/BMW_I3_Fa ... LIM_Module
by bitterandreal
Wed Nov 10, 2021 2:21 pm
Forum: Charging
Topic: BMW i3 CCS/charge port controller
Replies: 1187
Views: 3054570

Re: BMW i3 CCS/charge port controller

Coudn't resist and looked it up: WIKI: 0x3B4 EVSE info CP, PP & inlet voltage LIM I bet we don't wanna see F4 and don't wanna see BD and 9 and a counter? I need to check if the order of MSG's in the list is the order in the logfile , first appearance, but i think it is. These messages are in th...
by bitterandreal
Sun Nov 07, 2021 3:58 pm
Forum: Charging
Topic: BMW i3 CCS/charge port controller
Replies: 1187
Views: 3054570

Re: BMW i3 CCS/charge port controller

As far as different behavior with a 2019 LIM, it is possible that the newer LIM is offering ISO 15118 but it’s up to the station to decide which protocol it wants to speak… Sure the PLC communication could be different between a 2014 and a 2019 LIM, that part we don’t have direct control over. But ...
by bitterandreal
Sat Nov 06, 2021 5:22 pm
Forum: Charging
Topic: BMW i3 CCS/charge port controller
Replies: 1187
Views: 3054570

Re: BMW i3 CCS/charge port controller

Nice work! I'm happy there is some progress on this. Which version of the LIM are you using at the moment? Sure the station supports DIN 70121 as well and it should work with all LIM's. But it might be an idea to test a newer version to see if there is a different behaviour. The Ionity logs came fro...
by bitterandreal
Fri Nov 05, 2021 8:36 am
Forum: Charging
Topic: BMW i3 CCS/charge port controller
Replies: 1187
Views: 3054570

Re: BMW i3 CCS/charge port controller

Good question what is pilot status 4 (5% not charge ready) meaning? - Is the Qualcomm chip not ready? (It seems the Qualcomm chip is ready very quickly on the Efacec station) - Is the station sending the 5% PWM but no PLC (charge parameter discovery) which hangs or times out the LIM? - Is a charge r...
by bitterandreal
Thu Oct 28, 2021 9:38 pm
Forum: Charging
Topic: BMW i3 CCS/charge port controller
Replies: 1187
Views: 3054570

Re: BMW i3 CCS/charge port controller

I try to understand the differences in the signaling circuits.
I modified the J1772 version to match the IEC61851 / CCS2 circuit.
Please correct me...
by bitterandreal
Thu Oct 28, 2021 6:44 pm
Forum: Charging
Topic: BMW i3 CCS/charge port controller
Replies: 1187
Views: 3054570

Re: BMW i3 CCS/charge port controller

Jack Bauer wrote: Wed Oct 27, 2021 10:53 am Will test asap. Only thing left is the resistor value. Seems 4k7 might be a good place to start.
Yes 4k7 is most likely what you need.
by bitterandreal
Wed Oct 27, 2021 10:16 am
Forum: Charging
Topic: BMW i3 CCS/charge port controller
Replies: 1187
Views: 3054570

Re: BMW i3 CCS/charge port controller

I highly suspect something's up in the proximity circuit of Damien's set up. Of course it could be some CAN message that is messing with proximity in some way. I don't know if that's likely though. Other stations should be monitoring PP too. But I suspect ABB is particular about the resistance bein...
by bitterandreal
Tue Oct 26, 2021 8:56 pm
Forum: Charging
Topic: BMW i3 CCS/charge port controller
Replies: 1187
Views: 3054570

Re: BMW i3 CCS/charge port controller

Right, resistance testing update. 2k7 between pp and pe : No change to ac or dc charge behavior. ABB stations still say "charging will begin once power is available" and then time out. All other dc stations work as before. Only negative is the cp door flag from the lim stays in error. Pre...
by bitterandreal
Tue Oct 26, 2021 8:12 pm
Forum: Charging
Topic: BMW i3 CCS/charge port controller
Replies: 1187
Views: 3054570

Re: BMW i3 CCS/charge port controller

PP of the vehicle charging port is not connected to the charging station. The PP - PE resistor in the charging connector indicates the AC current capacity of the cable. For CCS Type 2 fast charging it is usually 1K5. That resistance would be measured higher by the LIM if the parallel resistor in the...
