Search found 141 matches

by alexbeatle
Mon Feb 26, 2024 10:23 pm
Forum: Charging
Topic: Scrappy CHAdeMO to CCS adapter for EV Conversions
Replies: 0
Views: 290

Scrappy CHAdeMO to CCS adapter for EV Conversions

Hello folks. As I was progressing with my wiring I had an idea, wanted to bounce off your brilliant minds. While CCS chargers are outnumbering the CHAdeMO, there're still many CHAdeMO ports out there and as the number of CCS vehicles is growing, CHAdeMO plugs are often unoccupied. I have a CCS charg...
by alexbeatle
Fri Feb 23, 2024 11:53 pm
Forum: Charging
Topic: BMW LIM based CCS2 Controller
Replies: 124
Views: 38724

Re: BMW LIM based CCS2 Controller

Cool. Looks like removing these two 60ohm resistors joined in series removed the CANbus termination, so the LIM can be put anywhere on the bus. Thanks. IMG_20240223_153430~2.jpg IMG_20240223_155007~2.jpg IMG_20240223_155655.jpg Edit. Now that my CANbus is wired and I'm coding my VCU, just wanted to ...
by alexbeatle
Fri Feb 23, 2024 4:41 pm
Forum: Charging
Topic: BMW LIM based CCS2 Controller
Replies: 124
Views: 38724

Re: BMW LIM based CCS2 Controller

Cannot seem to locate the termination resistor. Right on the inputs it has the filter circuit (zeners and chokes), then then traces disappear into another layer.
by alexbeatle
Fri Feb 23, 2024 1:48 am
Forum: Charging
Topic: BMW LIM based CCS2 Controller
Replies: 124
Views: 38724

Re: BMW LIM based CCS2 Controller

Must the LIM module be at the end of the CANbus and no workaround?
Reads 120Ohm between the CAN-H and CAN-L.
by alexbeatle
Sat Feb 17, 2024 5:09 pm
Forum: Tesla
Topic: SDU CAN bus connection
Replies: 1
Views: 209

SDU CAN bus connection

Hello folks.
A quick confirmation. If my SDU isn't the last device on the CANbus I just need to de-solder the R37 terminating resistor?
by alexbeatle
Thu Jan 11, 2024 4:33 pm
Forum: Projects
Topic: [WIP] Voltswagen T2 -76
Replies: 119
Views: 26488

Re: Voltswagen T2 -76

It does have a bolt pattern very similar to the VW one. Just a few mm's narrower on horizontal so I'm getting away with just widening the mounting bolt holes a bit in that direction. https://pixelfed.fi/storage/m/_v2/530130149058689089/f1538e3aa-7b3151/PMXU9LOwuc4x/XHrXiFuhnwdrYGaIhuJjmfv2wpETH3c2R...
by alexbeatle
Tue Dec 19, 2023 4:17 pm
Forum: Tesla
Topic: SDU brake lights output!?
Replies: 3
Views: 2986

Re: SDU brake lights output!?

While the OI firmware provides such an output at a regen level you can configure, the SDU and LDU boards do not export that signal to the outside world. I see. Is it by chance an option to send a regen message via CANbus? Curious if somebody actually triggers the brake lights during the regen if th...
by alexbeatle
Mon Dec 18, 2023 1:03 pm
Forum: Tesla
Topic: SDU brake lights output!?
Replies: 3
Views: 2986

SDU brake lights output!?

Hello folks. Quick question. How do you trigger the brake lights from the SDU OI board (I have v6) in your projects? I have a pressure switch on the brakes proportional valve, which I will use to trigger the max. regen - brk sw input to the OI bored. Planning to use the same signal to trigger the li...
by alexbeatle
Sat Dec 09, 2023 11:17 am
Forum: Classifieds
Topic: For Sale: Garage Cleanup - various EV parts
Replies: 5
Views: 3514

Re: For Sale: Garage Cleanup - various EV parts

youblare wrote: Tue Nov 21, 2023 1:29 am Do you still have the Tesla Gen3 1ph charger 1035647-00-G? I need to buy it mario games
Yes. Please PM me.
by alexbeatle
Wed Nov 15, 2023 6:48 am
Forum: General
Topic: EV car conversion hardware
Replies: 260
Views: 1183242

Re: EV car conversion hardware

Doig5710 wrote: Mon Nov 13, 2023 6:56 am Looks like a common fuel injector connector.
Bosch US car type
https://msel.co.nz/uscar-2-way-fuel-injector-connector/
Thank you!
Not sure if the ones I bought are Bosch, but "fuel injector" was the right key word to finding these on Amazon. 😁

https://a.co/d/51kPAin
by alexbeatle
Sun Nov 12, 2023 3:12 am
Forum: General
Topic: EV car conversion hardware
Replies: 260
Views: 1183242

Re: EV car conversion hardware

Folks.
Does anybody know what connector is used for the Tesla honk?
Inside dims 11x12 mm. 5.5 mm between pins. The pins are flat, not round.
by alexbeatle
Thu Oct 26, 2023 9:24 pm
Forum: Tesla
Topic: Parameters disappear after throttle! [SOLVED]
Replies: 10
Views: 4035

Re: Parameters disappear after throttle! [SOLVED]

Yeah, that's exactly what my interface looked like. The wiring for the power to my OI board was really thin, all I did was increase the gauge of the wires supplying 12v and it solved my issue. It sounds like the problem you're having is different because I wasn't able to spin my motor after I lost ...
by alexbeatle
Thu Oct 26, 2023 9:16 pm
Forum: Tesla
Topic: not getting POTNOM % [SOLVED]
Replies: 7
Views: 3467

Re: not getting POTNOM % [SOLVED]

Watching this thread... Mine does the same thing. So far I've been running the motor using half of my pack 116VDC (udcmin=100vdc) and the max I get out of potnom is 0.09. I can post the plots later. I'm on the latest firmware. The motor spins though. I'm switching between different tasks of the conv...
by alexbeatle
Thu Oct 19, 2023 6:09 pm
Forum: Tesla
Topic: Parameters disappear after throttle! [SOLVED]
Replies: 10
Views: 4035

Re: Parameters disappear after throttle! [SOLVED]

This indicates that for some reason the wifi module did a watchdog reset. Afterwards the stm32 still communicates at 1M baud and the wifi mod at 115k baud. It might be caused by the data rate being so low that the watchdog resets the wifi module. It doesn't affect drivability as the wifi module is ...
by alexbeatle
Thu Oct 19, 2023 6:13 am
Forum: Tesla
Topic: Parameters disappear after throttle! [SOLVED]
Replies: 10
Views: 4035

Re: Parameters disappear after throttle! [SOLVED]

I'm curious. Is this what your web-ui looks like when you "loose parameters"? My SDU board has good comms and runs fine when I test it on the bench However, when I put it in the drive unit in the car, bolt and torque it, it misbehaves. My laptop connects and I can browse the web-ui, but af...
by alexbeatle
Thu Oct 19, 2023 3:52 am
Forum: Inverters / Motor Controllers
Topic: Inverter Firmware 5.32.R
Replies: 29
Views: 9226

Re: Inverter Firmware 5.32.R

Loaded this firmware to SDU V6. My direction is set by switches: dirmode:Switches. Forward and reverse are swapped i.e when seldir=Forward; motor spins in reverse and rotordir=Reverse and vice versa. Has the option to swap signals in the UI been removed? Edit: ok. I found that there's a signal swap...
by alexbeatle
Sun Oct 15, 2023 4:15 pm
Forum: Tesla
Topic: Accelerator pedal dead zone
Replies: 98
Views: 40050

Re: Accelerator pedal dead zone

Has this or similar approach been pushed into the main firmware? Makes sense to me for the throttle calcs to depend on the motor rpm.

Thank you. This thread helps me understand why I had accel dead zone when running the motor for the first time, yesterday.
by alexbeatle
Sun Oct 15, 2023 4:06 am
Forum: Vehicle Control (VCU)
Topic: IVT-S Shut Inquiry
Replies: 8
Views: 5045

Re: IVT-S Shut Inquiry

Pretty sure you can open it up and remove the termination resistor 20211123_154108.jpg This is inside my unterminated, if you can find the termination resistor on yours and desolder it, it'll be then unterminated :D If it's the same PCB, there's a couple of unpopulated pads, maybe it has 2 x 60R in...
by alexbeatle
Sun Oct 15, 2023 2:58 am
Forum: Inverters / Motor Controllers
Topic: Inverter Firmware 5.32.R
Replies: 29
Views: 9226

Re: Inverter Firmware 5.32.R

Please test this, especially people who use the forward/reverse input. That topic should be settled for good. Loaded this firmware to SDU V6. My direction is set by switches: dirmode:Switches. Forward and reverse are swapped i.e when seldir=Forward; motor spins in reverse and rotordir=Reverse and v...
by alexbeatle
Tue Oct 10, 2023 1:16 am
Forum: Tesla
Topic: Tesla Small Drive Unit (SDU) Gear Box Fluid leaked
Replies: 11
Views: 3560

Re: Tesla Small Drive Unit (SDU) Gear Box Fluid leaked

Used the optimum gasket maker. Put a thin layer on the inside of the holes of the plastic cover to seal any gaps between plastic and wires. Made a thin gasket between the plastic cover and the metal of the of the frame. Thin layer inside of the sensor hole. Hand tightened. Torqued after 1h of curing...
by alexbeatle
Tue Oct 10, 2023 12:22 am
Forum: Tesla
Topic: SDU HV Wiring
Replies: 2
Views: 2786

Re: SDU HV Wiring

My cable came from the 70d model s. It uses 35mm2 cable. See attached.
by alexbeatle
Sun Oct 08, 2023 2:53 am
Forum: Classifieds
Topic: For Sale: Garage Cleanup - various EV parts
Replies: 5
Views: 3514

For Sale: Garage Cleanup - various EV parts

Cleaning up my garage. The following can be picked up for free in the SF Bay Area. Shipping additional. 1x OI SDU drop-in board V6. Brand new in the original packaging. - $280 I bought two of these, as I was planning to convert two cars. Using one at the moment, but cannot afford to do the second co...
